Novastar A10s Pro Receiving Card

DescriptionThe A10s Pro receiver card is a top-end LED receiving solution for high-end display systems that need consistent signal processing, powerful grayscale performance and high-precision image projection. The one-unit system can handle load capacities up to 512×512@60Hz and features exclusive technologies such as Dynamic Booster, Full-Grayscale Calibration and Image Booster for better contrast, more shadow detail and smoother low-brightness images.The receiving board enhances image uniformity by correcting luminance and chroma at the pixel level and supports HDR10 and HLG video playback for improved brightness range and natural-looking color reproduction. The integrated 22bit grayscale improvement boosts the grayscale processing 64 times to reduce the dark-area loss and improve the image smoothness during the low-brightness operation. You can also individually modify the RGB gamma values for enhanced white balance consistency and grayscale refinement.The A10s Pro is built for harsh LED installations requiring stable operation and easy maintenance. Features including loop redundancy, dual receiving-card backup, dual firmware storage, automatic calibration upload, module flash management, temperature monitoring, voltage monitoring, and Ethernet communication checking enhance the reliability of long-term operation. Support for image rotation in 90-degree intervals and free-angle rotation provide added installation freedom for innovative LED display setups.Input Interfaces2pcs high density connection interfaceDual Gigabit Ethernet supportRGB data compatible up to 32 groups in parallelSupport transfer of serial information in up to 64 groupsExpandable serial signal groups to 128 channelsTest switch interfaceTri-color LED signal support, reserved LVDS signal transfer capabilities with specific firmwareOutput Interface:Support of RGB signal transmission in parallelSupport serial data signal outputOutput Interface of the DCLK SignalSupport latch signal output, OE display enable signal outputsPostglow signal support for controlVideo input supportMaximum handling resolution up to 512×512 @60Hz Compatibility with HDR10 contents decodingHLG signal processing support22bit gray scale improvement technologyPrecise grayscale adjustment functionsSupport for dynamic contrast enhancementSupport for any-angle image rotation3D playback support with supported sending hardwareKey FeaturesBooster dynamic contrast enhancementFull Grayscale CalibrationBrightness correction for each individual pixel .Pixel-by-pixel color consistency adjustmentIndependent gamma setup for RGBFast dark-line and bright-line repairUpload automatic module calibrationOne click calibration factor applicationMapping topology finding features.Custom starting picture storageTemperature Checking AbilitySupport for voltage monitoringEthernet Communication Error DetectionDual power supply operation condition detectionConfiguration parameters backup functionFirmware read-back capabilitySupport for dual-receiving card failoverLoop redundancy protectionTwo-in-One Firmware Storage DesignStorage of dual calibration coefficientsElectrical CharacteristicsInput power range DC 3.3V-5.5VOperating voltage: Recommended 5.0VRated current 0.5 AStandard power consumption: 2.5 WOperating EnvironmentWorking temperature range: -20°C~ 70°CHumidity Operating: 10% RH to 90% RH non-condensingStorage EnvironmentStorage temperature range: –25 °C to 125 °CStorage humidity range: 0% RH to 95% RH (no condensation)Physical SpecificationsSize: 8.0 cm × 4.5 cm × 0.8 cmMax board thickness not exceeding 0.85 cmNet weight: 0.023 kgIncludes mounting hole grounding supportPackaging DetailsEach pack contains individual antistatic protection bagAnti-collision foam protection 40 receiving boards per cartonCarton Dimensions: 37.8cm x 19.0cm x 12.0cmAccessories IncludedStatic free storage bagProtective foam padding
