Novastar A10s Plus-N Receiving Card

DescriptionThe A10s Plus-N receiving card is made for handling sophisticated LED displays and can drive a single unit at a resolution of 512×512@60Hz. It has its own picture improvement technology that makes colors more accurate, makes grayscale depth much deeper, and makes transitions smoother, especially in gloomy environments. This makes the display look cleaner and more realistic, without common problems like uneven brightness or color inconsistencies.The A10s Plus-N makes sure that the whole screen is the same by allowing you to adjust the brightness and color of each pixel. It also lets you modify the gamma of the red, green, and blue channels separately, which helps fix problems with low brightness and keep the white output balanced. It has a big benefit in places where great visual accuracy and flexibility are needed because it can handle HDR, 3D displays, and rotating images in different ways.The hardware is built to be stable, using small, high-density connectors that reduce interference from dust and vibration. It can handle a lot of different types of data, such up to 32 simultaneous RGB sets or 64 serial streams, and it can handle even more. It is EMC Class B compliant, which makes it a good choice for places where signal dependability and electromagnetic compatibility are very important. It is a reliable solution for demanding LED display configurations because it has backup systems, monitoring tools, and smart module management functions.Input Ports32 sets of parallel RGB signal input are supported, and 64 sets of serial data input are supported (which can be expanded to 128 sets).High-density connection ports for reliable communicationReserved interface pins for bespoke expansion featuresInterfaces for OutputRGB data outputs using the HUB interfaceDisplay enable signal outputs (OE_RED, OE_GREEN, OE_BLUE)Outputs for the shift clock (DCLK1, DCLK2)Outputs for latch and control signalsVideo Input FeaturesMaximum load capacity is 512×512 pixels at 60Hz, and it works with HDR10 and HLG signals.3D signal output when used with a suitable transmitterBetter detail in low-brightness areas and smoother handling of grayscaleMain FeaturesAdvanced image enhancement with color range switching; 16-bit grayscale correction with 65,536 level adjustment; 22bit processing that improves grayscale depth by 64×; pixel-level brightness and color calibrationIndependent gamma tuning for the R, G, and B channelsProcessing with a delay of only one frameSupport for 90° step rotation and rotation at any angleSmart module integration for checking and fixing problemsAutomatic uploading of calibration data from modulesApplication of calibration coefficient with one clickMonitoring voltage and temperature in real timeA mapping function to find cabinetsBackup system with two cards for redundancyLoop redundancy to make sure the display never goes outDual backup protection for firmware and settingsSpecifications for electricityVoltage in: DC 3.8 V to 5.5 VCurrent rating: 0.5 AUsing 2.5 W of powerThe environment in which it worksThe temperature range for working is –20°C to 70°C.Humidity range: 10% to 90% RH, no condensationWhere to storeTemperature for storage: –25°C to 125°CHumidity range: 0% to 95% RH, no condensationSpecifications for the bodySize: 7.0 cm × 4.5 cm × 0.8 cmWeight: 0.022 kilogramInformation about packingEach unit comes with anti-static protection and foam padding. There are 40 receiving cards in each package.The box is 37.8 cm long, 19.0 cm wide, and 12.0 cm high.Accessories that come with itBag that doesn’t get staticFoam padding for protection
