Clipper Tactical Wind System (Apparent and True)

True wind display unit The Clipper True Wind Display shows apparent wind speed and direction and, when connected to a log or GPS, it can also show true wind speed and direction. Technical Data Mast transmitter supplied with 20m cable NMEA 0183 4800 Baud data sentence MWV – update rate = 10 per second Wind speed 0 to 99.9 Kts Wind direction 0 to 360 degrees Supply voltage nominal 12 Volts Wind sensor supply current 9mA Display Unit Shows Apparent and True* wind speed and direction (*when connected to NMEA 0183 output from a log or GPS) Supply voltage nominal 12 Volts Supply current 10mA (10mA for back light illumination Max) NMEA input sentence MWV Back light – 9 levels Pointer style – 2 Display wind speed – 0 to 99 Kts Display Wind angle – 0 to 360 degrees represented by 60 segments Display case size 110 x 110mm NMEA boat speed input either VHW from log or RMC from GPS for True wind speed and direction
